Oil Cooled Servo Voltage Stabilizer Specification

Input Voltage
340-480 V Volt (V)

Output Voltage
415 V 1% Volt (V)

Efficiency
98%

Frequency (MHz)
50-60 Hertz (HZ)

Phase
Three Phase

Warranty
Yes

Usage & Applications
Industrial

Weight
410 kg Kilograms (kg)

Ambient Temperature
-10 C to +45 C Celsius (oC)

Control System
Micro controller

Usage
Other

Insulation Resistance
>2 M

Design
Floor Mounted

Voltage Protection
Over/Under Voltage Protection

Display
Other

Dimension (L*W*H)
1070 x 870 x 1350 mm Millimeter (mm)

Rated Power
75 kVA

Current Type
AC

Waveform Distortion
Nil

Product Type
Servo Voltage Stabilizer

Operating Humidity
Up to 95% RH (non-condensing)

Transformer Type
Copper Wound

Bypass Arrangement
Manual/Automatic

Safety Features
Overload, Short-circuit & Phase Reversal Protection

Noise Level
< 50 dB

Model
HE7503

Regulation
1%

Cooling Type
Oil Cooled

Mounting Type
Floor Standing

Suitable For
Industrial Equipment, CNC Machines, Medical Devices

Enclosure
Weatherproof, Powder Coated

Surge Protection
Present

Response Time
< 2 ms

Serviceability
Easy Front Panel Access

Duty Cycle
Continuous

Oil Cooled Servo Voltage Stabilizer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

About Oil Cooled Servo Voltage Stabilizer

Grab the latest, top-rated HE7503 Oil Cooled Servo Voltage Stabilizer, engineered for magnificent voltage regulation in industrial settings. This matchless device features a pivotal copper wound transformer, floor-standing design, and cutting-edge microcontroller control system for seamless, continuous duty. With rapid response time (<2 ms), 1 regulation, and superb surge protection, your equipment remains secure. Enjoy weatherproof, powder-coated enclosure and low noise (<50 dB) operation. Suitable for CNC machines, medical devices, and industrial equipment, it delivers outstanding efficiency (98) and serviceability. Make your operations safer and smarter with HE7503.

Directions of Use & Application Areas

The HE7503 Oil Cooled Servo Voltage Stabilizer is designed for straightforward installation and floor mounting. Simply connect to the input AC voltage supply and select manual or automatic bypass as required. Ideal for industrial machinery, CNC equipment, and sensitive medical devices, it ensures stabilized voltage and protects against surges. To operate, refer to the easy front panel access for controls and status monitoring through the digital meter display, enhancing user convenience and safety.

Domestic & Export Market Details

HE7503 is a prominent choice across Indias main domestic market and widely sought after in top export regions. Packing & dispatch is handled professionally at the designated FOB port to ensure safe, timely delivery. Rates are competitive to match market standards, and each unit is delivered with reliable warranty support. Customers benefit from robust packaging and prompt shipment, making the stabilizer a preferred solution for global and local industry applications.

FAQs of HE7503 Oil Cooled Servo Voltage Stabilizer:

Q: How does the HE7503 Servo Voltage Stabilizer provide protection for industrial equipment?

A: The stabilizer features advanced microcontroller-based control, overload, short-circuit and phase reversal protection, as well as over/under voltage surge safeguards to ensure continuous equipment safety.

Q: What is the process for installing the HE7503 on site?

A: Installation involves placing the unit on a floor-standing location, connecting input and output terminals, configuring manual or automatic bypass, and monitoring via the digital meter display. Refer to the included user guide for details.

Q: When is it suitable to use the HE7503 stabilizer in industrial applications?

A: Use the HE7503 whenever precise voltage regulation and high reliability are required for CNC machines, medical devices, or other critical industrial equipment to prevent operational disruptions.

Q: Where can the HE7503 Servo Voltage Stabilizer be utilized?

A: It is suitable for factories, hospitals, manufacturing plants, and any location that demands robust and efficient voltage regulation under varying operating conditions.

Q: What are the main benefits of using the HE7503 model over conventional stabilizers?

A: HE7503 offers matchless efficiency (98), fast response time (<2 ms), minimal noise, easy serviceability, and enhanced protection features, ensuring reliable performance and longevity.

Q: How is the HE7503 packed and delivered to customers?

A: Packing & dispatch is handled securely at the specified FOB port, with careful packaging to prevent damage, ensuring the product is delivered promptly and safely as per the order rate.
